Chrome Brick
Chrome Oxide brick
Apparent Porosity (%) ≤18
Bulk Density (g/cm3) ≥3.30
Cold Crushing Strength (Mpa) ≥120
0.2Mpa Refractoriness Under Load T0.6 ℃ ≥1700
PRODUCT DESCRIPTION
Introduction:
Chrome Oxide Brick is a high-performance refractory material formulated from a chromium oxide–alumina (Cr₂O₃–Al₂O₃) matrix. Renowned for its ultra-high melting point (over 2200°C), it offers formidable resistance to chemical slag penetration and possesses exceptional load-bearing capacity, making it ideal for the most demanding industrial applications.
Features:
l Strong resistance to glass liquid erosion
l Excellent thermal shock resistance
l Long service lifetime
Applications:
Chrome Oxide Bricks are widely used in stacks and upstakes of glass fiber furnace; severe corrosion areas for colored glass furnace; sidewalls, tank bottom and forehearths of thermal insulation fiber glass furnace; discharge hole of ceramic frit glaze kiln, metallurgic molten bath and rotary kiln; zinc oxide melting furnaces, garbage destructors. CC-15 can also be used as superstructures and burner blocks for insulating fiber glass furnaces. CC-30 has higher corrosion resistance than AZS blocks when used in sidewall. It can be installed without preheating.
TECHNIQUE DATA
| Item | TY-CC-12 | TY-CC15 | TY-CC30 | TY-CC40 | TY-CC50 | TY-CC-60 |
| Cr2O3 % | ≥12 | ≥15 | ≥30 | ≥40 | ≥50 | ≥60 |
| ZrO2% | ≤3 | ≤5 | ≤5 | ≤5 | ≤5 | |
| Al2O3 % | ≥80 | ≥75 | ≥60 | ≥48 | ≥39 | ≥28 |
| Apparent Porosity % | ≤18 | ≤17 | ≤18 | ≤18 | ≤18 | ≤18 |
| Bulk Density g/cm3 | ≥3.3 | ≥3.25 | ≥3.3 | ≥3.35 | ≥3.45 | ≥3.65 |
| Cold Crushing Strength Mpa | ≥120 | ≥100 | ≥100 | ≥100 | ≥100 | ≥100 |
| 0.2Mpa Refractoriness Under Load T0.6℃ | ≥1700 | ≥1700 | ≥1700 | ≥1700 | ≥1700 | ≥1700 |
Note: All chemical-physical data are obtained based on the corresponding refractory bricks of standard size.
